Deaf Bonce Apocalypse ASA-6000.1 | 6000 Watt Power Amplifier
Key features
- Amplifier channels: 1
- RMS output at 4 ohms: 2150.0 W
- RMS output at 2 ohms: 3135 W
- RMS output at 1 ohm: 6000 W
Deaf Bonce Apocalypse ASA-6000.1 | 6000 Watt Power Amplifier is backordered and will ship as soon as it is back in stock.
Deaf Bonce Apocalypse ASA-6000.1 | 6000 Watt Power Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The Deaf Bonce Apocalypse ASA-6000.1 is a single-channel Class D car audio amplifier for bass-focused systems. Its power ratings vary by load and supply voltage, while adjustable low-pass and subsonic filters help shape the signal for a subwoofer setup.
Key Features & Benefits
- Class D design: The switching amplifier design supports high output in a compact chassis.
- Single-channel output: One channel provides a dedicated amplification path for a subwoofer.
- Low-pass adjustment: Set the upper frequency limit of the bass signal sent to the subwoofer.
- Subsonic adjustment: The filter lets you limit ultra-low frequencies that can cause excessive cone movement.
- Compact dimensions: The listed chassis size helps you plan space before installation.
Technical Specifications
| Model | ASA-6000.1 |
| Class | D |
| Number of the channels | 1 |
| Frequency response | 10 - 250 Hz |
| 1 Ohm RMS Power (14.4 V) | 6000 W |
| 1 Ohm RMS Power (12 V) | 4030 W |
| 2 Ohm RMS Power (14.4 V) | 3135 W |
| 4 Ohm RMS Power (14.4 V) | 2150 W |
| Minimum permissible load on the channel | 1 Ohm |
| Low pass filter | 35 - 250 Hz |
| Crossover | 24 dB/Oct |
| Subsonic filter | 10 - 50 Hz |
| Input terminal | 0 Ga |
| Output terminal | 8 Ga |
| Working voltage | 9 - 15 V |
| Signal-to-noise ratio | ≥ 85 dB |
| Size (WxLxH) | 28 x 9.4 x 2.5 inch |
Why Choose This Product?
The ASA-6000.1 combines a dedicated bass channel with adjustable filtering, giving you control over the frequencies sent to your subwoofer. Its separate RMS ratings at different loads and supply voltages help you compare its output with your system’s requirements.
Installation & Compatibility Notes
Keep the connected load at or above the stated 1 Ohm minimum. Check that your installation space can accommodate the 28 x 9.4 x 2.5 inch chassis, and plan the electrical setup around the listed 9 - 15 V working range and terminal specifications.
Frequently Asked Questions
What is the ASA-6000.1’s RMS power at 1 Ohm?
It is rated at 6000 W RMS at 14.4 V and 4030 W RMS at 12 V.
Can the amplifier run below a 1 Ohm load?
No. The listed minimum permissible channel load is 1 Ohm.
What do the low-pass and subsonic filters adjust?
The low-pass filter sets the upper frequency limit for the bass signal. The subsonic filter adjusts the lower-frequency cutoff.
How much space should I allow for the amplifier?
The listed dimensions are 28 x 9.4 x 2.5 inch (WxLxH). Check your available mounting space against these measurements.
