Audiopipe APCLE-10001D Class D Power Amplifier
Key features
- Amplifier channels: 1
- RMS output at 4 ohms: 380.0 W
- RMS output at 2 ohms: 600 W
- RMS output at 1 ohm: 1000 W
- FREQUENCY RESPONSE: 15Hz-180Hz
Audiopipe APCLE-10001D Class D Power Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Bring dedicated mono power to your subwoofer system with the Audiopipe APCLE-10001D Class D power amplifier. Its Class D design and full MOSFET circuitry support efficient operation, while selectable power ratings let you match the amplifier to a 1-, 2-, or 4-ohm load.
Key Features & Benefits
- Class D mono design: Powers a subwoofer system with a dedicated mono amplifier.
- Full MOSFET circuitry: Supports stable, efficient operation with reduced heat generation and low total harmonic distortion.
- Remote bass control: Adjust bass level from the dashboard with the included remote bass knob.
- Adjustable sound controls: Subsonic filtering and bass boost let you tailor the amplifier’s output.
- Built-in protection: Overload, thermal, short circuit, and low voltage protection help safeguard the amplifier and connected components.
Technical Specifications
| Specification | Value |
|---|---|
| Model | APCLE-10001D |
| Amplifier type | Class D mono |
| Peak power | 1000 watts |
| Continuous power, RMS @ 1 Ohm | 1000W (<1% Distortion) |
| Continuous power, RMS @ 2 Ohm | 600W (<2% Distortion) |
| Continuous power, RMS @ 4 Ohm | 380W (<1% Distortion) |
| Frequency response | 15Hz-180Hz |
| Input sensitivity level | 6-0.2V |
| S/N ratio | >90 dB |
| Subsonic filter | 15-50Hz |
| THD (all channels driven) | <1% |
| Working voltage | 9-16V |
| Circuitry | Full MOSFET circuitry |
| Protection circuits | Overload, thermal, short circuit, and low voltage protection |
| Remote bass control | Remote bass knob included |
Why Choose This Product?
The APCLE-10001D gives you three stated RMS power ratings across 1-, 2-, and 4-ohm loads, making load selection an important part of planning your system. Its remote bass knob also gives you a convenient way to adjust bass from the dashboard while listening.
Installation & Compatibility Notes
Match your subwoofer system’s impedance to the amplifier’s rated load options, and plan for a working voltage within 9-16V. Confirm your system’s electrical and installation requirements before connecting the amplifier.
Frequently Asked Questions
How much RMS power does the APCLE-10001D deliver?
It is rated at 1000W RMS at 1 Ohm, 600W RMS at 2 Ohm, and 380W RMS at 4 Ohm, with the distortion limits shown in the specifications.
What is the amplifier’s working voltage range?
The stated working voltage is 9-16V.
Does the amplifier include a remote bass control?
Yes. A remote bass knob is included for dashboard bass-level adjustment.
What filtering and sound controls are listed?
The amplifier has a 15-50Hz subsonic filter. Adjustable filters and bass boost are also listed.
