Audiopipe TXX-APD-12BL 12" Eye Candy Aluminum Cone Subwoofer
Key features
- Subwoofer size: 12.0 inches
- RMS power per subwoofer: 800 W
- Voice-coil options: D4
- MAGNET: Boasting a 120Oz magnet for strong power handling.
- FREQUENCY RESPONSE: 25-800Hz
- SENSITIVITY: 96 dB
Audiopipe TXX-APD-12BL 12" Eye Candy Aluminum Cone Subwoofer is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Add powerful bass and a distinctive candy-blue finish to your car audio system with the Audiopipe TXX-APD-12BL 12-inch subwoofer. Its inverted aluminum cone, ventilated voice coil, and cast aluminum basket are designed with heat management and durability in mind.
Key Features & Benefits
- Power handling: Rated at 800 watts RMS and 1,600 watts peak for system-planning reference.
- Inverted aluminum cone: The candy-blue cone is designed to improve heat dissipation and durability.
- Ventilated voice coil: The 3-inch, four-layer voice coil is designed to support performance and endurance.
- Cast aluminum basket: Its pipe-shaped design is made to handle heat while maintaining structural integrity.
- Multi-connect terminals: Patented terminals support parallel or series wiring configurations.
Technical Specifications
| Model | TXX-APD-12BL |
|---|---|
| Subwoofer size | 12" |
| Peak power | 1600 Watts |
| RMS power | 800 Watts |
| Magnet | 120Oz |
| Frequency response | 25-800Hz |
| Sensitivity | 96 dB |
| Voice coil | Dual 4 ohm, 3 inch, 4-layer high temperature black aluminum (BASV) |
| Impedance | 2 x 4 Ohms |
| Mounting depth | 178 mm (7") |
| Basket | Powdered pipe shape patent cast aluminum |
| Cone | Inverted candy blue aluminum |
| Finish | Candy blue with blue Ap |
| Terminals | Patented pipe multi-connect terminals for parallel or series configurations |
Why Choose This Product?
The TXX-APD-12BL pairs its candy-blue appearance with construction details focused on heat management. The ventilated voice coil, inverted aluminum cone, and cast aluminum basket make those design choices part of the subwoofer’s core specification.
Its dual 4-ohm voice coils and multi-connect terminals give you parallel or series wiring options when planning your system. Check your amplifier and wiring plan against the subwoofer’s ratings before choosing a configuration.
Installation & Compatibility Notes
Allow for the listed 178 mm (7") mounting depth, and check the available mounting space before installation. Match your system setup to the subwoofer’s 800-watt RMS rating and dual 4-ohm voice coils.
Frequently Asked Questions
What are the power ratings of the Audiopipe TXX-APD-12BL?
It is rated for 800 watts RMS and 1,600 watts peak.
What impedance does this subwoofer have?
It has dual 4-ohm voice coils, listed as 2 x 4 Ohms.
How much mounting depth should I allow?
The listed mounting depth is 178 mm (7"). Check the available space at the intended mounting location.
Can the subwoofer be wired in parallel or series?
Its patented pipe multi-connect terminals support parallel or series configurations.
