Audiopipe TXX-BDC-IV-12D2 12" Quad Stack Composite Cone Subwoofer
Key features
- Subwoofer size: 12.0 inches
- RMS power per subwoofer: 1100 W
- Voice-coil options: D2
- MAGNET: Boasting 4 magnets for strong power handling, 220 Oz
- FREQUENCY RESPONSE: 20-900Hz
- SENSITIVITY: 88dB
Audiopipe TXX-BDC-IV-12D2 12" Quad Stack Composite Cone Subwoofer is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Add a high-output 12-inch subwoofer to your car audio system with the Audiopipe TXX-BDC-IV-12D2 Quad Stack Composite Cone Subwoofer. Its four-magnet design, ventilated voice coil, and textured Kevlar Fiber Composite Non-press Paper Cone are built for high power handling and cone rigidity.
Key Features & Benefits
- Four-magnet design: The 220 Oz magnet assembly supports the subwoofer’s high power-handling design.
- Ventilated voice coil: Increased ventilation is designed to support performance and endurance.
- Composite cone: The textured Kevlar Fiber Composite Non-press Paper Cone is designed for improved rigidity.
- Powder-coated aluminum basket: Its dust-proof heat sink is constructed to allow high ventilation.
- Flexible connections: Patented Pipe Multi-Connect Terminals support parallel or series wiring configurations.
- Reinforced tinsel leads: Progressive quad-weaved leads on each side are designed for sound quality and durability.
Technical Specifications
| Brand | Audiopipe |
|---|---|
| Model | TXX-BDC-IV-12D2 |
| Product type | 12-inch Quad Stack Composite Cone Subwoofer |
| Peak power | 2200 Watts |
| RMS power | 1100 Watts |
| Magnet | 4 magnets; 220 Oz |
| Frequency response | 20-900Hz |
| Sensitivity | 88dB |
| Voice coil | Dual 2 ohms; 3 inch; 4-layer; high temperature black aluminum (BASV) |
| Impedance | 2 x 2 Ohms |
| Cone | Kevlar Fiber Composite Non-press Paper Cone with Texture finish |
| Basket | Powdered black paint aluminum basket |
| Dust cap | Composite glass fiber |
| Heat sink | Dust-proof heat sink, constructed for high ventilation |
| Tinsel leads | Quad-weaved, progressive weaved leads on each side |
| Terminals | Patented Pipe Multi-Connect Terminals; parallel or series configurations |
| Mounting depth | 200mm (7-7/8”) |
Why Choose This Product?
The TXX-BDC-IV-12D2 combines a dual 2-ohm voice coil with terminals designed for parallel or series connections. Its aluminum basket, ventilated heat sink, and increased voice coil ventilation give you specific construction details to consider when planning a high-power car audio system.
Installation & Compatibility Notes
Allow for the listed mounting depth of 200mm (7-7/8”) and check the available space in your installation. Confirm that your amplifier supports the intended wiring configuration and resulting load before connecting the dual 2-ohm voice coil.
Frequently Asked Questions
What does the D2 impedance designation mean?
The TXX-BDC-IV-12D2 has a dual 2-ohm voice coil, listed as 2 x 2 Ohms.
Can the subwoofer be wired in parallel or series?
Its patented Pipe Multi-Connect Terminals are designed to support parallel or series wiring configurations.
How much mounting depth should I allow?
The listed mounting depth is 200mm (7-7/8”). Check the available installation space before fitting the subwoofer.
What are its peak and RMS power ratings?
It is rated at 2200 Watts peak power and 1100 Watts RMS power.
