Audiopipe TXX-BDC-IV-18 18" Quad Stack Composite Cone Subwoofer
Key features
- Subwoofer size: 18.0 inches
- RMS power per subwoofer: 1700 W
- Voice-coil options: D4
- MAGNET: Boasting 4 magnets for strong power handling, 250 Oz
- FREQUENCY RESPONSE: 15-800Hz
- SENSITIVITY: 90dB
Audiopipe TXX-BDC-IV-18 18" Quad Stack Composite Cone Subwoofer is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Bring serious low-frequency output to your car audio system with the Audiopipe TXX-BDC-IV-18, an 18-inch quad-stack composite cone subwoofer. It combines 3,400 watts peak power handling with a Kevlar fiber composite non-press paper cone and increased voice coil ventilation.
Its dual voice coils and multi-connect terminals support series or parallel wiring. The textured cone is designed for improved rigidity, while the ventilated voice coil design supports performance and endurance.
Key Features & Benefits
- Power handling: 1,700 watts RMS and 3,400 watts peak give you the stated power ratings when planning a compatible car audio system.
- Quad-stack magnets: Four magnets, rated at 250 oz, form the subwoofer’s magnet assembly.
- Dual voice coils: The dual 4-ohm, 4-inch, 4-layer high-temperature black aluminum BASV voice coil offers series and parallel wiring options.
- Composite cone: The textured Kevlar fiber composite non-press paper cone is designed for improved rigidity.
- Aluminum basket: The powdered black paint basket pairs with a composite glass fiber dust cap and a dust-proof heat sink.
- Connection terminals: Patented pipe multi-connect terminals accept speaker wire up to 8 gauge for series or parallel coil wiring.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Audiopipe |
| Model | TXX-BDC-IV-18 |
| Product type | 18" Quad Stack Composite Cone Subwoofer |
| Peak power | 3400 Watts |
| RMS power | 1700 Watts |
| Magnets | 4 magnets; 250 Oz |
| Frequency response | 15-800Hz |
| Sensitivity | 90dB |
| Voice coil | Dual 4 ohm; 4 inch; 4-layer high temperature black aluminum (BASV) |
| Impedance | 2 x 4 Ohms |
| Mounting depth | 239mm (9-5/8") |
| Basket | Powdered black paint aluminum |
| Dust cap | Composite glass fiber |
| Cone | Kevlar Fiber Composite Non-press Paper Cone with Texture finish |
| Terminals | Patented pipe multi-connect terminals; accept up to 8 gauge speaker wire |
| Tinsel leads | Quad weaved; progressive weaved tinsel leads on each side |
Why Choose This Product?
The TXX-BDC-IV-18 brings together high stated power handling and construction details aimed at demanding car audio use. Its increased voice coil ventilation, four-magnet assembly, and dust-proof heat sink are designed with performance and endurance in mind.
The cone’s textured composite construction and the aluminum basket give you specific design features to consider when choosing an 18-inch subwoofer. Check the power ratings, impedance, and physical depth against the rest of your system before selecting it.
Installation & Compatibility Notes
Allow for the listed 239mm (9-5/8") mounting depth and confirm your intended installation space can accommodate an 18-inch subwoofer. The dual 4-ohm voice coils can be wired in series or parallel using the multi-connect terminals; plan the wiring for your system’s requirements.
The terminals accept up to 8 gauge speaker wire. Match your amplifier and wiring plan to the subwoofer’s stated power ratings and impedance.
Frequently Asked Questions
What are the RMS and peak power ratings?
The TXX-BDC-IV-18 is rated at 1,700 watts RMS and 3,400 watts peak.
What impedance does this subwoofer have?
It has dual 4-ohm voice coils, listed as 2 x 4 Ohms. Its terminals support series or parallel coil wiring.
How much mounting depth should I allow?
The stated mounting depth is 239mm (9-5/8"). Check the available space in your intended installation location.
What speaker wire can the terminals accept?
The patented pipe multi-connect terminals accept speaker wire up to 8 gauge.
