Audiopipe TXX-BDC-IV-8 8" Quad Stack Composite Cone Subwoofer
Key features
- Subwoofer size: 8.0 inches
- RMS power per subwoofer: 500 W
- Voice-coil options: D4
- MAGNET: Boasting 4 magnets for strong power handling, 150 Oz
- FREQUENCY RESPONSE: 40-1,500Hz
- SENSITIVITY: 85dB
Audiopipe TXX-BDC-IV-8 8" Quad Stack Composite Cone Subwoofer is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Add substantial low-frequency output to your car audio system with the Audiopipe TXX-BDC-IV-8 8-inch quad stack composite cone subwoofer. It combines 1000 watts peak power, 500 watts RMS power, and a textured Kevlar fiber composite non-press paper cone designed for improved rigidity.
Its dual 4-ohm voice coils and multi-connect terminals support parallel or series wiring configurations. Increased voice coil ventilation is designed to support performance and endurance.
Key Features & Benefits
- Quad-stack motor: Four magnets provide the strong power handling described for this subwoofer.
- Ventilated voice coil: Increased ventilation is designed to support endurance during use.
- Rigid cone design: The textured Kevlar fiber composite non-press paper cone is designed for improved rigidity.
- Reinforced construction: The powdered black paint aluminum basket, composite glass fiber dust cap, and dust-proof heat sink form the subwoofer’s construction.
- Flexible connections: Patented pipe multi-connect terminals allow parallel or series wiring configurations.
Technical Specifications
| Product category | 8" quad stack composite cone subwoofer |
|---|---|
| Peak power | 1000 Watts |
| RMS power | 500 Watts |
| Magnet | 4 magnets; 150 Oz |
| Frequency response | 40 -1,500Hz |
| Sensitivity | 85dB |
| Voice coil | Dual 4 ohm; 2.5 inch; 4-layer high temperature black aluminum (BASV) |
| Impedance | 2 x 4 Ohms |
| Cone | Kevlar Fiber Composite Non-press Paper Cone with Texture finish |
| Basket | Powdered black paint aluminum |
| Dust cap | Composite glass fiber |
| Heat sink | Dust-proof |
| Tinsel leads | Progressive weaved tinsel leads on each side of the subwoofer |
| Terminals | Patented pipe multi-connect terminals; parallel or series configurations |
| Mounting depth | 148 mm (5-7/8”) |
Why Choose This Product?
The TXX-BDC-IV-8 brings a quad-stack magnet design and a composite cone to an 8-inch subwoofer format. Its dual voice coils and multi-connect terminals give you parallel or series wiring options when planning your system.
Progressive weaved tinsel leads on each side and increased voice coil ventilation are part of its design. The textured cone finish and reinforced basket and heat sink complete a construction focused on rigidity, sound quality, and endurance.
Installation & Compatibility Notes
Check that your available mounting space accommodates the 148 mm (5-7/8”) mounting depth. Confirm that your amplifier and planned wiring suit the dual 4-ohm voice coils and the selected parallel or series configuration.
Frequently Asked Questions
What are the power ratings of the Audiopipe TXX-BDC-IV-8?
It is rated at 1000 watts peak power and 500 watts RMS power.
What impedance does this subwoofer have?
It has dual 4-ohm voice coils, listed as 2 x 4 Ohms.
How much mounting depth should I allow?
The stated mounting depth is 148 mm (5-7/8”). Check your available space against this measurement before installation.
Can the subwoofer be wired in parallel or series?
Its patented pipe multi-connect terminals support parallel or series wiring configurations. Confirm the final load suits your amplifier.
