Audiopipe TXX-BDX-15D2 15" Competition Subwoofer
Key features
- Subwoofer size: 15.0 inches
- RMS power per subwoofer: 2000 W
- Voice-coil options: D2
- FREQUENCY RESPONSE: 28-1,100Hz
- SENSITIVITY: 87dB
- MAGNET: Boasting a 375oz magnet for strong power handling
Audiopipe TXX-BDX-15D2 15" Competition Subwoofer is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Build a competition-oriented car audio system around the Audiopipe TXX-BDX-15D2 15-inch subwoofer. Its dual 2-ohm voice coil, 2000-watt RMS power rating, and 375-ounce magnet define a high-power design with features focused on ventilation and durability.
The 3-inch, 4-layer BASV voice coil and patented Pipe multi-connect terminals give you wiring options for parallel or series configurations. A reinforced paper cone, stitched surround, and vented T-yoke support the subwoofer’s performance-focused construction.
Key Features & Benefits
- 2000W RMS rating: Gives you a clear continuous power figure when selecting supporting audio equipment.
- Dual 2-ohm voice coil: Provides parallel and series wiring options through the multi-connect terminals.
- Voice coil ventilation: The improved ventilation and vented T-yoke are designed to help manage heat.
- Reinforced cone assembly: Black stitching reinforces the surround, while the sand-blasted non-press paper cone is designed for added rigidity.
- Aluminum basket and heat sink: The powdered black paint basket and dust-proof heat sink are part of the subwoofer’s sturdy construction.
- Injection-molded dust cap: The ultra-stiff IMPP cap complements the competition-focused design.
Technical Specifications
| Brand | Audiopipe |
|---|---|
| Model | TXX-BDX-15D2 |
| Product type | 15" competition subwoofer |
| Peak power | 4000 Watts |
| RMS power | 2000 Watts |
| Frequency response | 28-1,100Hz |
| Sensitivity | 87dB |
| Magnet | 375oz |
| Voice coil | Dual 2 ohm, 3 inch, 4-layer high temperature black aluminum (BASV) |
| Basket | Powdered black paint aluminum |
| Dust cap | Ultra-stiff injection molded PP (IMPP) |
| Cone | Black non-press paper cone with sand-blasted finish |
| Mounting depth | 242mm (9-1/2”) |
| Terminals | Patented Pipe multi-connect terminals; parallel or series wiring configurations |
Why Choose This Product?
The TXX-BDX-15D2 combines a substantial power rating with construction details aimed at reinforcement and heat management. Its black stitched surround, rigid cone design, and vented T-yoke make those choices visible in the subwoofer’s build.
The dual 2-ohm voice coil and multi-connect terminals offer wiring flexibility. Choose your configuration to suit your system design, and match supporting equipment to the resulting load and the subwoofer’s ratings.
Installation & Compatibility Notes
Allow for the listed 242mm (9-1/2”) mounting depth when planning the installation. Check the available space and mounting requirements in your intended enclosure or location before purchase.
The terminals support parallel or series wiring. Confirm the final impedance and amplifier requirements for your chosen configuration before connecting the subwoofer.
Frequently Asked Questions
What are the peak and RMS power ratings?
The TXX-BDX-15D2 is rated at 4000 Watts peak power and 2000 Watts RMS power. Use the RMS rating when comparing continuous power requirements.
What impedance does this subwoofer have?
It has a dual 2-ohm voice coil. Its terminals allow parallel or series wiring configurations.
How deep is the subwoofer?
The listed mounting depth is 242mm (9-1/2”). Check this against the space available for your installation.
What does the vented T-yoke do?
The vented holes are designed to enhance heat dissipation and improve sound quality, with minimal distortion stated as a design aim.
What should I check before choosing an amplifier?
Match the amplifier to the subwoofer’s 2000 Watts RMS rating and the impedance produced by your selected wiring configuration.
