Audiopipe TXX-FB1000-S4 10" Shallow Mount Subwoofer,Single 4 Ohms Woofer
Key features
- Subwoofer size: 10.0 inches
- RMS power per subwoofer: 300 W
- Voice-coil options: S4
- MAGNET: 60 Oz high-strength magnet ensures strong bass control and reliable operation under load.
- FREQUENCY RESPONSE: 40- 1,600Hz
- SENSITIVITY: 88 dB
Audiopipe TXX-FB1000-S4 10" Shallow Mount Subwoofer,Single 4 Ohms Woofer is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The Audiopipe TXX-FB1000-S4 is a 10-inch shallow-mount subwoofer for adding low-frequency output to a car audio system. Its single 4-ohm voice coil, 300-watt RMS rating, and 94 mm mounting depth help you assess power and space requirements before installation.
Key Features & Benefits
- Power handling: 300 watts RMS and 600 watts peak provide clear ratings for matching your system.
- Voice coil: The 3-inch, 4-layer high-temperature BASV coil is designed for heat dissipation and durability.
- Cone and surround: The textured non-press paper cone and foam surround are designed to improve cone rigidity.
- Magnet: The 60 oz high-strength magnet supports bass control and operation under load.
- Multi-connect terminals: Patented pipe terminals allow parallel or series wiring configurations.
- Construction: The aluminum basket, composite glass fiber dust cap, and dust-proof heat sink form the subwoofer’s stated construction.
Technical Specifications
| Model | TXX-FB1000-S4 |
|---|---|
| Product type | 10-inch shallow-mount subwoofer |
| Peak power | 600 watts |
| RMS power | 300 watts |
| Impedance | 1 x 4 Ohms |
| Magnet | 60 oz high-strength magnet |
| Frequency response | 40–1,600 Hz |
| Sensitivity | 88 dB |
| Voice coil | 3-inch, 4-layer high-temperature BASV; single 4 Ohm |
| Basket | Aluminum |
| Dust cap | Composite glass fiber |
| Heat sink | Dust-proof |
| Cone and surround | Textured non-press paper cone with foam surround |
| Mounting depth | 94 mm (3-3/4") |
Why Choose This Product?
This Audiopipe subwoofer combines shallow-mount dimensions with a 300-watt RMS rating, making mounting depth and amplifier matching key considerations. Its stated cone, voice coil, and heat-sink design details help you compare its construction with your system’s needs.
Installation & Compatibility Notes
Check that your available mounting space accommodates the 94 mm (3-3/4") mounting depth. Match the amplifier and wiring plan to the subwoofer’s single 4-ohm impedance and power ratings. The terminals support parallel or series wiring configurations.
Frequently Asked Questions
What is the Audiopipe TXX-FB1000-S4’s impedance?
It has a single 4-ohm voice coil, listed as 1 x 4 Ohms.
How much power is it rated for?
The subwoofer is rated at 300 watts RMS and 600 watts peak.
How much mounting depth should I allow?
The listed mounting depth is 94 mm (3-3/4"). Check the available space in your intended location before installation.
Can the terminals be wired in parallel or series?
Yes. The product details state that its patented pipe multi-connect terminals allow either parallel or series wiring configurations.
