DS18  |  SKU: NVY-6CKEVLAR-N4

6.5” 2-Way Coaxial Loudspeaker with Kevlar Cone and Neodymium Magnet | 200W RMS 4-Ohm

$500.00
Shipping calculated at checkout.

Description

KEY FEATURES

  • Kevlar Cone

    Kevlar Cone

  • Patent-Pending Hybrid Tweeter Design

    Patent-Pending Hybrid Tweeter Design

  • High Sensitivity

    High Sensitivity

  • Water-Resistant IP65

    Water-Resistant IP65

  • Neodymium Magnet

    Neodymium Magnet

  • Perfect for Motorcycles and Powersports

    Perfect for Motorcycles and Powersports

Built For All Elements

The NVY-6CKEVLAR-N4 is a premium 6.5" coaxial speaker, engineered to deliver the full-range of frequencies in motorcycle and powersports builds.




Made for Motorcycles

With a shallow 2.6” mounting depth on standard 6.5” sizing, and dual push terminals for simplified wiring and advanced tuning, the NVY-6CKEVLAR-N4 slides cleanly into factory locations and fairings.

Imagen 1 Imagen 2 Imagen 3 Imagen 4 Imagen 5 Imagen 6 Imagen 7 Imagen 8 Imagen 9 Imagen 10 Imagen 11 Imagen 12 Imagen 13 Imagen 14 Imagen 15 Imagen 16 Imagen 17 Imagen 18 Imagen 19 Imagen 20 Imagen 21 Imagen 22 Imagen 23 Imagen 24 Imagen 25 Imagen 26 Imagen 27 Imagen 28 Imagen 29 Imagen 30 Imagen 31 Imagen 32 Imagen 33 Imagen 34 Imagen 35 Imagen 36 Imagen 37
Patent Pending
Hybrid Tweeter Design

At the center of the speaker is a patent pending tweeter assembly designed to mimic the output and dispersion of a compression driver. The sealed soft rubber surround acts as a barrier for the tweeters internals.

NVY-Grade Durability

A Kevlar-reinforced woofer cone offers the perfect mix of rigidity and responsiveness for higher SPL, louder output, and deeper tones than standard paper cones. Wrapped in a marine-grade aluminum basket, the entire assembly is IP65-rated waterproof and UV resistant for long-haul durability.

  • Specifications
  • Nominal Diameter: 6.5" / 165mm
  • Nominal Impedance: 4 Ohms
  • RMS Power Handling: 200W
  • MAX Power Handling: 400W
  • Sensitivity (1w/1m): 95dB
  • Frequency Response: 80Hz-20kHz
  • Recommended High-Pass Crossover: 120Hz
  • Number of Ways: 2-Way
  • Water-Resistant Rating: IP65
  • Cone Shape: Curvilinear
  • Speaker Terminals: Dual Push 16ga (TW/WF)
  • Pair

  • Woofer Specifications
  • Voice Coil Diameter: 2” / 50.6 mm
  • Voice Coil Former Material: Fiber Glass
  • Winding Material: CCAW
  • Cone Material: Kevlar
  • Surround Material: Cloth
  • Basket Material: Aluminum
  • Basket Color/Finish: Black Corrugated
  • Magnet Material: Neodymium
  • Magnet Weight: 8.8 Oz

  • Thiele & Small Parameters
  • Equivalent Volume Vas: 2.38L / 0.84ft3
  • Excursion (one way) Xmax: 1.2mm
  • Free Air Resonance Fs: 171Hz
  • Mechanical Factor Qms: 13.31
  • Electrical Factor Qes: 0.61
  • Total Factor Qts: 0.58
  • Moving Mass Mms: 9.974g
  • Mechanical Compliance Cms: 0.079 mm/N
  • BL Factor BL: 8.42
  • Diaphragm Area Sd: 132.73cm2
  • DC Resistance Re: 3.2 Ohms

  • Tweeter Specifications
  • Nominal Diameter: 1.35" / 34mm
  • Voice Coil Diameter: 1" / 25.4mm
  • Voice Coil Material: Kapton
  • Winding Material: CCAW
  • Diaphragm Material: Aluminum
  • Magnet Material: Neodymium (N38H)
  • Magnet Weight: 0.44 Oz

  • Measurements
  • Overall Diameter: 6.5" / 165mm
  • Overall Depth: 2.9" / 73.5mm
  • Front Mount Baffle Cutout: 5.6" / 143.5mm
  • Mounting Depth: 2.6" / 66mm
  • Motor Diameter: 3.6" / 92mm
