DS18 EXL-X8.2D EXL-X 8" Subwoofer 1200 Watts Dvc 2-Ohms
Key features
- Subwoofer size: 8.0 inches
- RMS power per subwoofer: 600 W
- Voice-coil options: D2
- Frequency response: 38 Hz–1 kHz
- Voice-coil diameter: 2.5 inches
- Magnet material: Ferrite
DS18 EXL-X8.2D EXL-X 8" Subwoofer 1200 Watts Dvc 2-Ohms is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The DS18 EXL-X8.2D 8-inch car subwoofer brings 600W RMS power handling to compact-to-mid-sized bass builds. Its dual 2-ohm voice coils offer wiring flexibility, while the red aluminum basket gives the sub a distinctive look.
Key Features & Benefits
- 600W RMS handling: Supports sustained playback when paired with a capable amplifier.
- 2+2-ohm dual voice coil: Gives you options for matching the subwoofer to an amplifier.
- 8-inch cone: Fits a standard 8-inch subwoofer footprint for compact installations.
- Paper and glass-fiber cone: Combines stiffness and damping for accurate bass reproduction.
- Ferrite magnet and aluminum basket: Provide the specified magnetic structure and rigid frame.
Technical Specifications
| Specification | Value |
|---|---|
| Nominal Diameter | 8" / 203.2 mm |
| Nominal Impedance | 2+2 ohms |
| RMS Power Handling | 600W |
| Maximum Power Handling | 1200W |
| Sensitivity (1w/1m) | 89dB |
| Frequency Response | 38Hz–1kHz |
| Voice Coil Diameter | 2.5" / 63.5 mm |
| Voice Coil Former Material | Black Aluminum |
| Cone Material | Non Pressed Paper + Glass fiber |
| Dust Cap Material | PPI |
| Basket Material / Finish | Aluminum Basket; Glossy Red |
| Magnet Material | Ferrite |
| Weight | 130 oz |
| Sealed Internal Volume | 0.3 ft3 |
| Ported Internal Volume | 0.5 ft3 |
| Port Size | 1" x 8" x 10.56" |
| Port Tuning | 55 Hz |
| Ported Box Output | 42 Hz |
| Overall Diameter | 8.58" / 218 mm |
| Overall Depth | 6.61" / 168 mm |
| Front Mount Baffle Cutout | 7.36" / 187 mm |
| Mounting Depth | 5.51" / 140 mm |
Why Choose This Product?
The EXL-X8.2D combines an 8-inch format with 600W RMS power handling, making it an option for compact-to-mid-sized builds. Choose a sealed enclosure for the specified sealed-box volume, or a ported design using the listed volume, port dimensions, and tuning.
Installation & Compatibility Notes
Check the subwoofer’s 8.58" overall diameter, 5.51" mounting depth, and 7.36" front-mount baffle cutout against your available space. Match the amplifier and wiring plan to the 2+2-ohm voice coils and the intended load.
For a sealed enclosure, the listed internal volume is 0.3 ft3. For a ported enclosure, use the listed 0.5 ft3 internal volume, 1" x 8" x 10.56" port, and 55 Hz tuning specification.
Frequently Asked Questions
What is the difference between the RMS and maximum power ratings?
The EXL-X8.2D is rated for 600W RMS power handling and 1200W maximum power handling. Use the RMS rating when assessing sustained amplifier output.
What does 2+2 ohms mean?
This subwoofer has two 2-ohm voice coils. Plan the wiring and amplifier match around the intended load.
What enclosure sizes are listed?
The recommended sealed internal volume is 0.3 ft3. The ported internal volume is 0.5 ft3, with a 1" x 8" x 10.56" port tuned to 55 Hz.
Will it fit my installation?
Compare the 8.58" overall diameter, 6.61" overall depth, 7.36" front-mount cutout, and 5.51" mounting depth with your available space.
