Nemesis Audio NA-10SLM V.2 D4 10″ 500W RMS Dual 4-Ohm Shallow Subwoofer
Key features
- Subwoofer size: 10.0 inches
- RMS power per subwoofer: 500 W
- Voice-coil options: D4
- Voice coil: 2.5-inch, 4-layer
- Frame material: Die-cast aluminum
- Mounting diameter: 9.84 inches
Nemesis Audio NA-10SLM V.2 D4 10″ 500W RMS Dual 4-Ohm Shallow Subwoofer is backordered and will ship as soon as it is back in stock.
Nemesis Audio NA-10SLM V.2 D4 10″ 500W RMS Dual 4-Ohm Shallow Subwoofer is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Make room for meaningful bass in a compact car audio installation with the Nemesis Audio NA-10SLM V.2 D4 10-inch shallow subwoofer. Its dual 4-ohm voice coils, 500W RMS power handling, and 1.97-inch motor depth suit space-limited builds where mounting depth is tight.
Key Features & Benefits
- Shallow motor: The 1.97-inch motor depth supports compact installations, including under-seat applications.
- Dual 4-ohm voice coils: The dual-coil design provides wiring flexibility when matching the subwoofer to an amplifier and enclosure.
- 500W RMS power handling: Match it with an appropriately powered amplifier and stay within the subwoofer’s thermal and mechanical limits.
- 75 oz magnet and vented T-yoke: The magnetic assembly is designed to support controlled bass and airflow around the motor.
- Die-cast aluminum frame: The rigid frame helps limit panel flex during installation.
- Long, pressed terminals: These binding posts accommodate thicker speaker wire for secure connections.
Technical Specifications
| Power Handling | 500W RMS |
|---|---|
| Impedance | Dual 4-ohm |
| Woofer Diameter | 10.63" |
| Mounting Diameter | 9.84" |
| Magnet | 75 oz |
| Voice Coil | 2.5" – 4 Layer |
| T-yoke | Chromed, Vented |
| Frame | Die-cast Aluminum |
| Gasket | Rubber |
| Efficiency | 83.8 dB |
| Motor Depth | 1.97" |
| Binding Post Terminals | Long & Pressed Terminal |
Why Choose This Product?
The NA-10SLM V.2 D4 is built around the constraints of a shallow car audio installation. Its compact motor depth helps when available space is limited, while the 2.5-inch, 4-layer voice coil and vented T-yoke support thermal management during playback.
A rubber gasket helps seal the mounting surface and dampen vibration. The 83.8 dB efficiency rating is useful to consider when planning amplifier output for your system.
Installation & Compatibility Notes
Check that your enclosure or mounting surface can accommodate the 9.84-inch mounting diameter and 1.97-inch motor depth. The listed 10.63-inch woofer diameter is a separate measurement from the required mounting cutout.
Confirm that your amplifier and enclosure are suitable for a dual 4-ohm subwoofer. Use an amplifier appropriate for its 500W RMS power handling, and keep operation within the driver’s thermal and mechanical limits.
Frequently Asked Questions
What does dual 4-ohm mean?
The subwoofer has two 4-ohm voice coils. Account for its dual-coil configuration when planning the wiring and matching it to your amplifier and enclosure.
How much power can the NA-10SLM V.2 D4 handle?
Its power handling is rated at 500W RMS. Pair it with an appropriately powered amplifier and stay within the subwoofer’s thermal and mechanical limits.
What mounting space does it require?
The listed mounting diameter is 9.84 inches, and the motor depth is 1.97 inches. Check both against your available space before installation.
What kind of terminals does it have?
It uses long, pressed binding post terminals, which accommodate thicker speaker wire.
