Rockford Fosgate Punch P300-8P 8" 300-Watt Powered Enclosure
Key features
Drivers and amplifier included
- Compatible woofer size: 8 inches
- Woofer mounting capacity: 1
- Enclosure design: Ported
- Integrated amplifier: 300 W RMS
- Inputs: Speaker-level or RCA line-level
- Remote bass level control: Included
Rockford Fosgate Punch P300-8P 8" 300-Watt Powered Enclosure is backordered and will ship as soon as it is back in stock.
Rockford Fosgate Punch P300-8P 8" 300-Watt Powered Enclosure is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Add controlled low-frequency output without assembling a separate subwoofer, amplifier, and enclosure. The Rockford Fosgate Punch P300-8P is an 8-inch powered subwoofer enclosure with a built-in 300-watt RMS Class-D amplifier, designed for truck installations and compact car audio systems.
Its vented enclosure, adjustable bass controls, and included remote level control give you options for shaping and adjusting bass in your vehicle.
Key Features & Benefits
- Integrated system: The woofer, amplifier, and enclosure are combined in one unit.
- Flexible inputs: Low-level RCA and high-level speaker inputs support factory or aftermarket audio signals.
- Adjustable sound: Set the low-pass crossover from 50 Hz to 200 Hz, adjust bass EQ from 0 dB to +12 dB, or use the phase switch.
- In-cabin control: The included remote bass level control lets you adjust output from the cockpit.
- Signal sensing: Intelligent auto turn-on/off detects audio signal presence, eliminating the need for a separate turn-on wire.
Technical Specifications
| Product | Rockford Fosgate Punch P300-8P 8" 300-Watt Powered Enclosure |
|---|---|
| Product type | Self-contained powered subwoofer enclosure |
| Woofer | 8" high-output woofer optimized for the built-in 300-watt amplifier |
| Amplifier | Built-in Class-D amplifier; 300 W RMS; optimized closed-loop design |
| Enclosure | Vented; 5/8" MDF with heat-activated vinyl finish |
| Frequency response | 30 Hz to 200 Hz |
| Low-pass crossover | 12 dB/octave; adjustable from 50 Hz to 200 Hz |
| Bass EQ | 0 dB to +12 dB boost |
| Phase adjustment | On-board phase switch |
| Inputs | Low-level (RCA) and high-level (speaker); includes 1 RCA pair (L/R summed) |
| Turn-on | Intelligent auto turn-on/off detects audio signal presence |
| Remote control | Remote bass level control included |
| Protection and compliance | Thermal and over/under voltage protection; CEA-2031 and CEA-2006 compliant |
| Dimensions | 11.4" H x 17.6" W x 5.6" D |
| Weight | 19 lbs (8.6 kg) |
| Power wiring | Power input B+/GND with 8 AWG; REM with 18 AWG wiring |
| Fuses | 20 Amp (2 x 10 Amp ATO) |
Why Choose This Product?
The P300-8P brings the woofer, amplifier, and vented enclosure together in a compact package. Its crossover, bass EQ, and phase switch let you tailor the subwoofer’s output to your system, while the remote control makes level adjustments accessible from the cabin.
Installation & Compatibility Notes
The enclosure is designed for truck installations and compact spaces. Before choosing a mounting location, compare its 11.4" H x 17.6" W x 5.6" D dimensions with your available space.
Connect it using the input type that matches your audio signal: low-level RCA or high-level speaker inputs. The specified power wiring is 8 AWG for B+/GND and 18 AWG for REM.
Frequently Asked Questions
Can I connect the P300-8P to a factory audio system?
It has high-level speaker inputs for factory signals, as well as low-level RCA inputs for compatible aftermarket signals.
Can I adjust the bass to suit my system?
Yes. It has an adjustable 50 Hz to 200 Hz low-pass crossover, 0 dB to +12 dB bass EQ, and an on-board phase switch.
Can I change the bass level from inside the vehicle?
Yes. A remote bass level control is included for in-vehicle adjustments.
What space should I allow for the enclosure?
The enclosure measures 11.4" high, 17.6" wide, and 5.6" deep. Check these dimensions against your intended mounting location.
What power wiring and fuses are specified?
The listed wiring is 8 AWG for B+/GND and 18 AWG for REM. The specified fuses are 20 Amp (2 x 10 Amp ATO).
Explore More
Want to learn more about Rockford Fosgate? Explore our Rockford Fosgate brand profile. Shop the P300-8P at 12 Volt Outlet to add adjustable sub-bass in a compact enclosure.
