DS18 6XL600-8 XL 6.5" Mid-Range Loudspeaker 300 Watts Rms 8-Ohm (each)

Product Overview

Bring clear, assertive vocals and midrange detail to your car audio system with the DS18 6XL600-8 6.5-inch mid-range loudspeaker. Its 300-watt RMS power handling, 97 dB sensitivity, and 8-ohm impedance suit high-power builds that need a dedicated midrange driver.

Key Features & Benefits

• 300 watts RMS: Handles continuous power at the stated RMS rating for demanding audio builds.
• 97 dB sensitivity: Delivers strong output at the stated 1W/1m measurement condition.
• Midrange coverage: The 60Hz–12.5kHz frequency response covers a broad range of vocal and instrumental detail.
• Vented construction: Ample ventilation supports heat dissipation during prolonged high-volume listening.
• Secure connections: Polished, spring-loaded push terminals make speaker-wire connections straightforward.

Technical Specifications

Why Choose This Product?

The 6XL600-8 is designed for car audio builds where vocals and midrange presence need their own dedicated driver. Its 8-ohm impedance and 97 dB sensitivity are useful considerations when planning a multi-driver system and matching the speaker to an amplifier.

A satin-black aluminum basket, 34-ounce ferrite magnet, and non-pressed paper cone with cloth surround give you specific construction details to weigh when choosing a midrange loudspeaker. The stated frequency range extends from 60Hz to 12.5kHz.

Installation & Compatibility Notes

Check your mounting location against the 5.9-inch front cutout, 3.14-inch mounting depth, and 6.7-inch overall diameter before installation. The listed overall depth is 3.5 inches; account for the available space behind the mounting surface.

Confirm that your amplifier and system design accommodate an 8-ohm speaker. The recommended hi-pass crossover is 100Hz. Plan crossover settings and installation around your full system configuration.

Frequently Asked Questions

What is the difference between the RMS and MAX power ratings?

The speaker is rated for 300 Watts RMS and 600 Watts MAX. Keep the two ratings distinct when matching system components.

What amplifier setup should I check before choosing this speaker?

Confirm that your amplifier and system design support an 8-ohm load and account for the speaker’s 300 Watts RMS rating.

What mounting space does the 6XL600-8 need?

Plan for a 5.9-inch front mount cutout and 3.14-inch mounting depth. The overall dimensions are 6.7 inches in diameter and 3.5 inches deep.

What hi-pass crossover is recommended?

The listed recommended hi-pass crossover is 100Hz.
