Hifonics ZS35CX ZEUS 3.5 Inch Speakers

Name: Hifonics ZS35CX ZEUS 3.5 Inch Speakers
Brand: Hifonics
SKU: 806576226703
Price: 19.99 USD
Availability: InStock

$19.99 $23.99

Shipping calculated at checkout.

Key features

Speaker size: 3.5″
RMS power per speaker: 25 W
Speaker impedance: 4.0 ohms
Frequency response: 80Hz-20kHz
Cone: Alpha-cellulose
Voice coil: Copper winding on Kapton former

Description

Product Overview

Bring clear high frequencies and responsive midbass to a vehicle location designed for a 3.5-inch speaker with the Hifonics ZS35CX ZEUS 3.5-inch 2-way coaxial car speakers. Their 1-inch Neo-Mylar soft dome tweeter, Alpha-Cellulose poly woofer cone, and passive Butterworth crossover are designed to work together in a compact speaker pair.

Use them in a vehicle location that accepts 3.5-inch drivers behind an existing factory panel. Check the available mounting space and connection type before installation.

Key Features & Benefits

Two-way coaxial design: The tweeter and woofer share a compact speaker assembly for midbass and treble reproduction.
Neo-Mylar soft dome tweeter: The 1-inch tweeter is designed for clear high-frequency sound and impact resistance.
Alpha-Cellulose poly cone: The lightweight, rigid cone supports responsive sound and bass performance.
Moisture-resistant rubber surround: The surround couples with the cone and is designed to resist moisture.
Overcoil cooling system: Air exchange over the voice coil through the spider supports heat dissipation.
Flexible connections: Connect using spade connectors or direct soldering, as appropriate for the installation.

Technical Specifications

Specification	Details
Brand	Hifonics
Series	ZEUS
Product type	Coaxial speaker
Speaker size	3.5"
RMS power handling	25 W
Peak power handling	125 W
Impedance	4 Ohms
Frequency response	80Hz - 20kHz
Sensitivity	88 dB
Crossover	Passive Butterworth
Crossover slope	6kHz 12dB
Tweeter size	1"
Tweeter material	Neo-Mylar Soft Dome
Cone material	Alpha-Cellulose Poly
Surround material	Rubber
Basket material	Stamped Steel
Mounting depth	3.8 cm
Mounting diameter	8.7 cm
Overall dimensions	24.8 × 15.2 × 7.3 cm
Weight	0.9 kg
Color	Black
Compatible vehicles	Universal; locations accepting 3.5-inch speaker drivers behind OEM factory panels, with a mounting depth of 3.8 cm
Voice coil former	Kapton
Voice coil material	Pure copper
Spider	Epoxy-infused natural fiber
Cooling system	Overcoil; air is exchanged over the voice coil through the spider
Frame	Anti-resonant stamped steel basket
Motor	Ferrite magnet
Connectors	Spade connectors or direct solder
Grilles	Not included; typically installed behind an OEM panel
Warranty	1 Year manufacturer's warranty

The epoxy-infused natural fiber spider combines flexibility with strength. A high-temperature adhesive bonds the cone and surround. The anti-resonant stamped steel basket is designed to minimize flex, ringing, and related distortion. The ferrite motor provides the speaker's magnetic field in a compact design.

Why Choose This Product?

The ZS35CX combines a woofer and tweeter in a 3.5-inch coaxial speaker, making it an option for locations where that driver size is accepted. Its passive Butterworth crossover provides a transition between midrange and midbass output and the tweeter.

The Kapton voice coil former is lightweight and helps dissipate heat. A moisture-resistant rubber surround, overcoil cooling system, and sturdy stamped steel basket address different parts of the speaker's construction without changing its compact format.

Installation & Compatibility Notes

Confirm that your vehicle location accepts a 3.5-inch driver and has at least the stated 3.8 cm mounting depth. The listed mounting diameter is 8.7 cm; check the opening and surrounding clearance before purchase.

These speakers are intended for installation behind an OEM panel, and grilles are not included. The stated connection options are spade connectors or direct soldering. Check your audio system's requirements against the 4 Ohms impedance and 25 W RMS power handling before connecting.

Frequently Asked Questions

What are the power rating and impedance?

Each speaker is rated at 25 W RMS, with 125 W peak power handling and 4 Ohms impedance.

What mounting space is required?

The stated mounting depth is 3.8 cm, and the mounting diameter is 8.7 cm. Confirm that both measurements suit your installation location.

Are grilles included?

No. These speakers are typically installed behind an OEM factory panel.

What are the tweeter and woofer made from?

The 1-inch tweeter uses a Neo-Mylar soft dome. The woofer cone is Alpha-Cellulose poly, with a rubber surround.

Explore More

Explore the Hifonics range at 12 Volt Outlet and compare products for your car audio setup. Want to learn more about Hifonics? Explore our Hifonics brand profile.

Download: View/Download (706.8 KB)

Brand	Hifonics
Series	ZEUS
Product Type	Coaxial Speaker
Speaker Size	3.5"
RMS Power Handling	25 W
Peak Power Handling	125 W
Impedance	4 Ohms
Frequency Response	80Hz - 20kHz
Sensitivity	88 dB
Crossover Slope	6kHz 12dB
Tweeter Size	1"
Tweeter Material	Neo-Mylar Soft Dome
Cone Material	Alpha-Cellulose Poly
Surround Material	Rubber
Basket Material	Stamped Steel
Mounting Depth	3.8 cm
Mounting Diameter	8.7 cm
Overall Dimensions	24.8 × 15.2 × 7.3 cm
Weight	0.9 kg
Color	Black
Compatible Vehicles	Universal

Feature	Benefit
Tweeters	1 inch: Clear highs while handling plenty of power without sound harsh. Neo-Mylar Soft Dome Tweeter: Impact Resistant Tweeter Elements, Great sound quality and increased reliability. Kapton: Lightweight and efficiently dissipates heat.
Cone Material	Alpha-Cellulose Cones: Light weight for speed and very rigid for deep bass.
Surround / Cone Coupling	Rubber: Moisture Resistant Rubber Surround with high Mid-Bass Impact. High Temperature Adhesive: Special adhesive is chosen to create a permanent bond between the cone and the surround.
Voice Coil / Former Assembly	Pure Copper: Creates strong magnetic field with a very thin extrusion. Kapton: Lightweight and efficiently dissipates heat.
Spider	Epoxy infused Natural Fiber: Natural fiber allows flexibility while the epoxy which gives strength during the manufacturing process.
Cooling System	Overcoil: Air is exchanged over the voice coil through the spider.
Crossover	Passive Butterworth: Smooth transition of frequencies from midrange/midbass to the tweeter element.
Frame	Anti-Resonant Stamped Steel Basket: Very strong with minimal harmonics or distortions from flex or ringing.
Motor	Ferrite Magnet: Creates a strong magnetic field while remaining small enough to fit nearly every application.
Connectors	Spade: Use spade connectors or solder direct for the best connection.
Grills	No: These speakers are typically installed behind an OEM panel.
