Hifonics ZS46CX ZEUS 4x6 Inch Speakers

Product Overview

The Hifonics ZS46CX ZEUS 4x6-inch coaxial car speakers bring a dedicated tweeter and woofer into factory 4x6-inch speaker locations. Their 40-watt RMS power handling, Alpha-Cellulose Poly cones, and 1-inch Neo-Mylar soft dome tweeters support clear sound with defined mid-bass and high frequencies.

Key Features & Benefits

• Two-way coaxial design: A woofer and tweeter share each speaker location for mid-bass and high-frequency reproduction.
• Alpha-Cellulose Poly cones: The rigid cone material supports the speaker’s mid-bass response.
• Neo-Mylar soft dome tweeters: The 1-inch tweeters handle detailed high frequencies.
• Moisture-resistant rubber surrounds: The surrounds pair with the woofer cones in the speaker assembly.
• Stamped steel baskets: The anti-resonant baskets are designed to limit harmonic distortion and mechanical flexing.
• Copper voice coils and Kapton formers: This voice-coil structure is designed to dissipate heat during demanding playback.

Technical Specifications

Why Choose This Product?

The ZS46CX combines a 4x6-inch woofer and tweeter in a coaxial design for factory-location replacement. Its specified frequency response is 55Hz - 19kHz, while the integrated passive Butterworth crossover network supports the two-way speaker system.

With 40 W RMS and 200 W peak power handling per pair, these speakers offer clear rating information when you’re comparing them with your audio system. Check the amplifier’s output and speaker impedance when planning a replacement.

Installation & Compatibility Notes

These speakers are intended for vehicles with factory 4x6-inch speaker locations in doors, dashboards, or rear side panels. The source lists standard spade connectors for connection.

Before installation, compare the 14.0 x 8.8 cm cutout and 7.6 cm mounting depth with the available opening and clearance. The listed outside dimensions are 15.1 x 9.8 cm. Grilles are not included; the speakers are designed for factory dash or door panel locations.

Frequently Asked Questions

What is the power handling of the Hifonics ZS46CX?

The speakers are rated at 40 watts RMS and up to 200 watts peak power handling per pair.

What impedance should I account for?

The listed impedance is 4 Ohm. Check that your connected audio equipment supports this speaker load.

What are the mounting dimensions?

The cutout is 14.0 x 8.8 cm, and the mounting depth is 7.6 cm. The listed outside dimensions are 15.1 x 9.8 cm.

Will these fit my vehicle?

They are described for vehicles with factory 4x6-inch speaker locations in doors, dashboards, or rear side panels. Compare the opening and available depth with the listed dimensions before installation.

Are grilles included?

No. Grilles are not included.
