Audio Code AXC ZR046 4x6" Bullet Midrange Speakers (Pair)

Product Overview

Bring focused midrange output to a custom car audio system with the Audio Code AXC ZR046 4x6-inch bullet midrange speakers. This dedicated midrange pair has an integrated bullet phase plug and is designed for active or passive multi-way systems—not as a standalone coaxial speaker.

Key Features & Benefits

• Integrated bullet phase plug: Helps control midrange dispersion for focused on-axis sound and reduced off-axis coloration.
• 4x6-inch speaker size: Offers a rectangular format for installations where a round midrange driver may not fit.
• 100W RMS power handling: Provides a stated continuous power rating for planning an amplifier match.
• 90dB sensitivity: The 1W/1m rating helps you assess output efficiency when planning a multi-channel system.
• Pair of speakers: The package includes two speakers for a stereo midrange installation.

Technical Specifications

Why Choose This Product?

The AXC ZR046 is intended to handle the midrange portion of a multi-way car audio system. Its 100Hz–12.5kHz frequency response covers the stated range from upper bass through lower treble, while a separate tweeter and subwoofer can handle the higher and lower frequencies.

The 4x6-inch shape can suit builds where a round driver is not an option. The bullet phase plug is a practical design detail for systems where controlled midrange dispersion and listening focus matter.

Installation & Compatibility Notes

Use these speakers with an active or passive crossover. For an active three-way setup, the supplied guidance recommends a high-pass filter at 100–150Hz and a low-pass filter at 4–6kHz to hand off to a tweeter.

A dedicated amplifier channel rated at 50–100W RMS at 4 ohms is the stated pairing recommendation. A DSP amplifier with active crossover capability is also recommended for this type of system. Check your vehicle’s speaker location and fitment before purchase; the 4x6-inch format is described for standard dash, door, and rear deck locations, but fit varies by vehicle.

Frequently Asked Questions

Are the Audio Code AXC ZR046 speakers sold individually?

No. The package quantity is a pair, with two speakers included.

Do these speakers need a crossover?

Yes. They are dedicated midrange speakers intended for use with an active or passive crossover.

What crossover settings are recommended for an active three-way system?

The supplied guidance recommends a 100–150Hz high-pass filter and a 4–6kHz low-pass filter.

What amplifier rating is recommended?

The stated recommendation is a dedicated channel rated at 50–100W RMS at 4 ohms.

Will the 4x6-inch speakers fit my vehicle?

Check the speaker location and fitment for your vehicle before ordering. The 4x6-inch format is associated with dash, door, and rear deck locations, but fitment can vary.
