DS18 EXL-SQ6.9 is a 6x9" 2-way coaxial car speaker built for high-output systems, delivering full-range sound from a glass-fiber cone with a dedicated tweeter for precise highs. Its 3-ohm impedance and 160W RMS (560W max) power handling make it a strong choice for aggressive, detail-driven installations.
- 6x9" 2-Way Coaxial: built-in woofer and tweeter deliver full-range sound from a single mounting footprint.
- Impedance: 3 Ohm — low impedance eases integration with high-powered amplifiers for dynamic response.
- RMS Power: 160 Watts — continuous power handling for sustained, clean output.
- Max Power: 560 Watts — peak capability for transient musical peaks and impactful moments.
- Frequency Response: 55 Hz – 22 kHz — broad range from deep bass to extended highs for a complete soundtrack.
- Sensitivity: 90 dB / 1W / 1m — efficiency rating indicating how loud it gets with a given input.
- Tweeter: 1.14" PEI Dome — crisp high-frequency detail with fast transient response.
- Voice Coil: BASV 1.14" — coil size supports power handling and heat management for cleaner output.
- Cone Material: Glass Fiber Cone — stiff and lightweight, reduces distortion and improves accuracy.
- Magnet: Neodymium magnet — provides strong flux in a compact, efficient motor assembly.
- Magnet Material: Strontium — magnet material specified for this assembly.
- Magnet Weight: 19.8 oz — part of the motor’s mass contributing to its dynamic response.
- Surround: Rubber edge — durable surround that supports controlled cone motion.
The EXL-SQ6.9 is designed for high-powered builds where 6x9" mounting is available, offering strong midbass, clear highs, and efficient, low-distortion performance thanks to the glass-fiber cone and PEI tweeter. Its 3-ohm load and substantial power handling provide headroom for powerful amplifiers, while the lightweight motor assembly and stiff cone translate to rapid transient response and accurate musical reproduction across genres.
